The FANUC CRX robot plugins for Asyril’s products guide you to quick and easy integration into the robotics environment. Download the appropriate plugin and benefit from the new functions dedicated to our flexible feeding solutions directly in Roboguide.
Plugins
FANUC CRX
EYE+ or EYE+ XTD
Plugin to download for :
- EYE+ and Asycube used together
- EYE+ XTD
The interface is available in English and Japanese, based on the robot's configuration.
- Includes two configurations wizards
- Wizard for configuring the network between your robot and your EYE+
- Wizard for performing the hand-eye calibration
- Includes block functions for easy programming through the teaching editor
- Efficient integration of EYE+ to control the part quantity and the position of the parts on the Asycube.
- Includes classical control commands accessible in TP programs (KAREL instructions)
Compatibility
On Asyril side
- EYE+ with Asycube 50, 80, 240, 380 and 530
- EYE+ XTD
- Maximum 1 EYE+ controller or 1 EYE+ XTD controller can be used per FANUC CRX robot
- Required version 3.0.0 or higher
On FANUC side
- Available for all robot models with R-30iB PLUS controller compatible Tablet TP
- Software version V9.40 or higher
- Options that must be installed on the robot controller:
- User socket messaging (R648)
- Tablet TP (S527)
